Gas Pressure Regulator with Solenoid Valve, 1/2" Rp, 24V DC, IP65

The HONEYWELL KROMSCHRODER REG,PRSS RED,1 1/2 RP,GAS W/SOL VAD 240R is a pressure regulator intended for use in the control and regulation of gas pressure within compatible systems. This unit integrates a solenoid valve and is compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It features an internal thread outlet connection and operates on a mains voltage of 24 V DC.

Key features include:

• Class A pressure regulator to EN 88 standard
• Class A solenoid valve to EN 161 standard
• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Features an opening and closing mechanism as per product specifications
• Enclosure rated IP65 according to IEC standard 60529; provides limited protection against dust ingress and low-pressure water jets from any direction
• Certified to applicable FM, SA, and EU standards
• Equipped with a pilot lamp indicator
• Electrical connection via M20 cable gland
• Right-side accessories: Pressure switch (30–110 mbar) with test point; left-side accessories: two screw plugs
