Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, 35–100 mbar

The HONEYWELL KROMSCHRODER VAD1-/25R/NW-100A is a pressure regulator intended for use in the regulation and monitoring of gas pressure in industrial systems. This unit integrates both a Class A pressure regulator to EN 88 standards and a Class A solenoid valve to EN 161, compatible with gas, air, and biologically produced methane. It features an integrated pilot lamp for operational status indication and is constructed with an IP65-rated enclosure.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Features rapid actuation
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on the right side of the connection box
• FM and SA approved; EU certified
• No inlet flange; size 1 configuration
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left-side screw plugs
