Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, 35–100 mbar

The HONEYWELL KROMSCHRODER VAD350R/NQGR-100A is a pressure regulator rated for regulation and control of gas pressure in industrial and commercial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane within specified parameters. It features an integrated pilot lamp, rapid actuation, and is constructed to meet IP65 ingress protection standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Mains voltage: 24 V DC; electrical connection via M20 cable gland
• FM and SA approved; EU certified
• Size 1 configuration with no inlet flange
• Valve seat reduced design; right-side accessories include a pressure switch (30–110 mbar) with test point at outlet, left side includes two screw plugs
