Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65

The HONEYWELL KROMSCHRODER VAD125R/NW-100A is a pressure regulator intended for use in applications requiring gas pressure regulation within specified parameters. This unit features an integrated solenoid valve and is constructed in accordance with Class A standards per EN 88 and EN 161; compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. The device operates at a maximum inlet pressure of 500 mbar (7 psig); adjustable outlet pressures from 35–100 mbar.

Key features include:

• Integrated pilot lamp for status indication
• IP65-rated enclosure for ingress protection
• FM and SA approvals; EU certified
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Valve seat reduced design; optional right-side pressure switch available (range: 30–110 mbar)
• Test point located on right-hand pressure switch; left side equipped with two screw plugs
