Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65

The HONEYWELL KROMSCHRODER VAD125R/NW-50A is a pressure regulator intended for use in controlling and monitoring gas pressure within compatible systems. This unit features an integrated solenoid valve compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It meets Class A requirements according to EN 88 for pressure regulators and EN 161 for solenoid valves. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar.

Key features include:

• Integrated pilot lamp
• IP65-rated enclosure
• FM and SA approvals; EU certified
• Outlet: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Valve seat reduced design with optional right-side pressure switch (30–110 mbar)
• Test point available on right-hand side for outlet pressure switch; left side includes two screw plugs Features rapid actuation mechanism
