Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD1-/25R/NW-50A is a pressure regulator intended for regulation and control of gas pressure in various systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as per manufacturer specifications. The device features rapid actuation mechanism, operates at a maximum inlet pressure of 500 mbar (7 psig), and provides an outlet pressure range between 35–100 mbar.

Key features include:

• Integrated pilot lamp for operational status indication
• Rated IP65 according to IEC standard, providing specified levels of ingress protection against dust and water
• FM and SA approvals; EU certified
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC with M20 cable gland electrical connection on the right side of the connection box
• Size 1 configuration with reduced valve seat design
• Right-side accessory: Pressure switch adjustable from 30–110 mbar with test point at outlet pressure; left-side accessory: two screw plugs
