Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD240R/NW-100A is a pressure regulator intended for use in controlling and regulating gas pressure within compatible systems. This unit features an integrated solenoid valve compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It is rated for operation at a maximum inlet pressure of 500 mbar (7 psig) with an adjustable outlet pressure range between 35–100 mbar.

Key features include:

• Integrated pilot lamp
• Protection rating: IP65
• FM and SA approved; EU certified
• Features rapid actuation mechanism
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Valve seat reduced design with optional accessories such as a right-side pressure switch (30–110 mbar) and left-side screw plugs
