Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD120R/NQ-50A is a pressure regulator intended for use in controlling and monitoring gas pressure within specified industrial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at mains voltage of 24 V DC, and features rapid actuation mechanism.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Protection rating: IP65
• FM and SA approved; EU certified
• Equipped with pilot lamp for status indication
• Electrical connection via M20 cable gland on right side of connection box
• No inlet flange; reduced valve seat design
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left-side two screw plugs
