Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated
Mfr # KS88011841
Zoro # G415401130
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD115R/NW-25B is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane. It features an outlet with DN 15 (1/2") Rp internal thread, operates at mains voltage of 24 V DC, and includes electrical connections via M20 cable gland. The device is constructed to IP65 standards and carries FM and SA approvals as well as EU certification.
Key features:
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet pressure range: 35–100 mbar
- Features rapid actuation mechanism
- Integrated pilot lamp indicator
- No inlet flange; right-side connection box attachment
- Valve seat reduced design; size 1 configuration
- Accessories include right-hand side pressure switch (30–110 mbar) with test point on outlet side; left side has two screw plugs
