Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD365/50R/NW-100A is a pressure regulator intended for regulation and control of gas pressure in various systems. It features integrated solenoid valve functionality and meets Class A requirements according to EN 88 and EN 161 standards, making it suitable for use with gas, air, and biologically produced methane as specified by manufacturer guidelines. The unit operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar.

Key features include:

• Integrated pilot lamp for operational status indication
• IP65 rated enclosure for dust-tight and water jet protection
• FM and SA approvals; EU certified
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Outlet: DN 15 (1/2") Rp internal thread; no inlet flange included
• Valve seat reduced design with optional right-side pressure switch (30–110 mbar)
• Test point available on right-hand side for outlet pressure monitoring; left side includes two screw plugs
