Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD240R/NQSR-50A is a pressure regulator intended for use in the regulation and control of gas pressure in industrial and commercial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar.

Key features include:

• Integrated pilot lamp for status indication
• IP65 rated enclosure for ingress protection
• FM and SA approvals; EU certified
• Features rapid actuation mechanism
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC with M20 cable gland electrical connection on the right side of the connection box
• Size 1 configuration with reduced valve seat
• Accessories: right-side pressure switch (30–110 mbar) test point, left-side two screw plugs
