Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD1-/25R/NW-50A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane as specified by manufacturer guidelines. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at mains voltage of 24 V DC, and includes electrical connections via M20 cable gland.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Features rapid actuation mechanism
• IP65 rated enclosure
• Certified to applicable FM, SA, and EU standards
• Integrated pilot lamp indicator
• No inlet flange; right-side connection box attachment
• Valve seat: reduced type; size 1 configuration
• Accessories include right-hand mounted pressure switch (30–110 mbar) with test point, left side screw plugs
