Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD240R/NWSR-50A is a pressure regulator intended for use in gas pressure regulation applications. This unit includes a Class A pressure regulator compliant with EN 88 standards with a Class A solenoid valve to EN 161, compatible with gas, air, and biologically produced methane. It features an integrated pilot lamp and is enclosure rated IP65.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Mains voltage: 24 V DC; electrical connection via M20 cable gland
• Features quick actuation
• FM and SA approved; EU certified
• Size 1 configuration; no inlet flange included
• Accessories include right-side pressure switch (30–110 mbar) with test point, left-side screw plugs
