Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD1-/20R/NW-25A is a pressure regulator intended for regulation and control of gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as per manufacturer specifications. It features an integrated pilot lamp, rapid actuation mechanism, and electrical connection via M20 cable gland.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical specification: mains voltage 24 V DC
• Enclosure rating: IP65
• Certifications: FM, SA approved; EU certified
• No inlet flange; size 1 configuration
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet pressure and two screw plugs on the left side
