Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated
Mfr # KS88025174
Zoro # G415401956
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD240R/NW-25A is a pressure regulator intended for use in applications involving gas pressure regulation and monitoring, as specified by manufacturer guidelines. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane within specified parameters. It features an outlet connection of DN 15 (1/2" Rp internal thread) and operates at a maximum inlet pressure of 500 mbar (7 psig). The device is equipped with a pilot lamp for status indication and has an IP65 rating.
Key features include:
- Outlet pressure range: 35–100 mbar
- Mains voltage: 24 V DC; electrical connection via M20 cable gland
- Features rapid actuation mechanism
- FM and SA approved; EU certified
- No inlet flange; size 1 configuration
- Valve seat reduced design
- Right-side accessories: Pressure switch (30–110 mbar), test point for outlet pressure
- Left-side accessories: Two screw plugs
