Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated
Mfr # KS88027350
Zoro # G515402358
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD365/50R/NW-25A is a pressure regulator intended for regulation and control of gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane as per manufacturer specifications. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at a maximum inlet pressure of 500 mbar (7 psig), and provides an adjustable outlet pressure range from 35 to 100 mbar.
Key features include:
- Integrated pilot lamp for operational status indication
- Electrical connection via M20 cable gland; mains voltage: 24 V DC
- Features rapid actuation mechanism
- IP65 rated enclosure for ingress protection
- FM and SA approvals; EU certified product
- No inlet flange; reduced valve seat design
- Right-side accessories: pressure switch (30–110 mbar) with test point on outlet side; left-side accessories: two screw plugs
