Gas Pressure Regulator with Solenoid Valve, 3/4" NPT, 24V DC, IP65
Mfr # KS88008466
Zoro # G715390479
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER REG,PRESS,3/4NPT,GAS,CPS R VAD 1T /20N/N is a pressure regulator intended for use in applications involving control and monitoring of gas pressure in industrial systems, as specified by the manufacturer. This unit features a Class A pressure regulator according to EN 88 standards and includes a Class A solenoid valve compliant with EN 161; compatible with gas, air, and biologically produced methane within specified parameters. It operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range of 35-100 mbar.
Key features include:
- Connection size: 3/4" NPT
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet: DN 15 (1/2") Rp internal thread
- Electrical connection: M20 cable gland; mains voltage: 24 V DC
- Features an actuator mechanism capable of rapid operation per product specifications
- IP65 rated enclosure
- FM and SA approved; EU certified
- Includes pilot lamp indicator
- Accessories include right-side pressure switch (30–110 mbar) with test point, left side has two screw plugs
