Gas Pressure Regulator with Solenoid Valve, 35–100 mbar, DN15, IP65

The HONEYWELL KROMSCHRODER VAD350R/NW-100A is a pressure regulator intended for use in controlling gas pressure within industrial systems as specified. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161). It features rapid actuation mechanism, an integrated pilot lamp, and electrical connection via M20 cable gland with mains voltage at 24 V DC.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Outlet size: DN 15 (1/2") Rp internal thread
• Protection rating: IP65
• Approvals: FM and SA approved; EU certified
• No inlet flange; reduced valve seat design
• Size designation: Size 1
• Accessories include right-side mountable pressure switch (30–110 mbar) with test point for outlet pressure, plus two screw plugs on the left side
