Gas Pressure Regulator with Solenoid Valve, 35–100 mbar, DN15, IP65
Mfr # KS88021372
Zoro # G815402225
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD3-/50R/NK-50A is a pressure regulator intended for use in the control and regulation of gas pressure within compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane as specified by manufacturer guidelines. It features an outlet with DN 15 (1/2") Rp internal thread and operates at a maximum inlet pressure of 500 mbar (7 psig). The device includes a pilot lamp for status indication and features a mechanism capable of rapid actuation as specified in product documentation.
Key features include:
- Outlet pressure range: 35–100 mbar
- Maximum inlet pressure: 500 mbar (7 psig)
- Electrical connection: M20 cable gland, mains voltage 24 V DC
- IP65 rated enclosure
- FM and SA approved; EU certified
- No inlet flange; reduced valve seat design
- Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side, left-side screw plugs
