Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN 15, 24V DC
Mfr # KS88004749
Zoro # G615399916
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD1-/20R/NW-50A is a pressure regulator intended for use in applications involving gas pressure regulation and monitoring. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and features an outlet connection of DN 15 (1/2'') Rp internal thread. The device includes a pilot lamp for status indication and is constructed according to IP65 standards.
Key features:
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet connection: DN 15 (1/2'') Rp internal thread
- Outlet pressure range: 35–100 mbar
- Features rapid actuation mechanism
- Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side
- Valve seat reduced; size designation: Size 1
- Includes accessory: right-side pressure switch (30–110 mbar) with test point, left-side screw plugs
- No inlet flange included
- FM and SA approved; holds relevant EU certification
