Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN 15, 24V DC
Mfr # KS88025747
Zoro # G315403197
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD240R/NPGL-50A is a pressure regulator intended for use in applications involving the regulation and monitoring of gas pressure, as specified by manufacturer guidelines. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane within specified parameters. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and features an outlet connection of DN 15 (1/2") Rp internal thread. It is equipped with a pilot lamp for status indication and has an IP65 rating.
Key features include:
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet connection: DN 15 (1/2") Rp internal thread
- Outlet pressure range: 35–100 mbar
- Electrical requirements: Mains voltage 24 V DC; M20 cable gland electrical connection
- Features rapid actuation mechanism per product specifications
- FM and SA approved; EU certified
- Integrated pilot lamp for visual status indication
- Accessories include right-side mountable pressure switch (30–110 mbar) with test point, left-side screw plugs
- No inlet flange included
