Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN 15, 24V DC

The HONEYWELL KROMSCHRODER VAD240R/NP-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit features a Class A pressure regulator to EN 88 standards and incorporates a Class A solenoid valve to EN 161, making it suitable for use with gas, air, and biologically produced methane as specified by manufacturer guidelines. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar. It includes a pilot lamp for status indication and offers electrical connection via an M20 cable gland with mains voltage at 24 V DC.

Key features:

• Pressure regulator: Class A to EN 88; solenoid valve: Class A to EN 161
• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Features rapid actuation mechanism
• IP65 rated enclosure
• FM and SA approved; EU certified
• No inlet flange; size designation: Size 1
• Electrical connection via M20 cable gland on right side of box, mains voltage at 24 V DC
• Accessories include right-side test point for outlet pressure switch (30–110 mbar), left-side screw plugs
