Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN 15, IP65

The HONEYWELL KROMSCHRODER VAD2-/40R/NYGL-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. It features an integrated solenoid valve . The unit operates at a maximum inlet pressure of 500 mbar (7 psig) and provides outlet pressure regulation within the range of 35–100 mbar. This model includes a pilot lamp for status indication and is housed in an enclosure rated to IP65.

Key features include:

• Class A pressure regulator according to EN 88
• Class A solenoid valve per EN 161 standards
• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Provides rapid actuation as per manufacturer specifications
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Size designation: Size 1
• FM and SA approved; EU certified
• Accessories include right-side pressure switch (30–110 mbar), test point for outlet pressure, left-side screw plugs
