Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, 24V DC

The HONEYWELL KROMSCHRODER VAD240R/NWSR-50A is a pressure regulator intended for use in controlling and monitoring gas pressure within specified industrial applications. This unit integrates a Class A pressure regulator to EN 88 standards and a Class A solenoid valve to EN 161, compatible with gas, air, and biologically produced methane. It features rapid actuation, an integrated pilot lamp, and electrical connection via M20 cable gland.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• IP65 rated enclosure
• FM and SA approved; EU certified
• Size 1 configuration; no inlet flange
• Valve seat reduced design with right-side accessories including a pressure switch (30–110 mbar) and test point for outlet pressure; left side includes two screw plugs
• Operates on mains voltage of 24 V DC
