Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, 24V DC

The HONEYWELL KROMSCHRODER VAD2-/40R/NW-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar. The device includes a pilot lamp for status indication, and has an IP65 rating.

Key features:

• Integrated Class A pressure regulator to EN 88 standard
• Built-in Class A solenoid valve to EN 161 standard
• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Electrical connection via M20 cable gland; mains voltage: 24 V DC
• Features rapid actuation mechanism with pilot lamp indicator
• FM and SA approved; EU certified; IP65 rated enclosure
• Size designation: Size 1
