Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, 24V DC
Mfr # KS88021777
Zoro # G715402332
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD240R/NW-100A is a pressure regulator intended for regulation and control of gas pressure within specified system parameters. This unit integrates a Class A pressure regulator according to EN 88 standards and features a solenoid valve compliant with EN 161, compatible with gas, air, and biologically produced methane as specified. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar. It includes a pilot lamp for operational status indication and is constructed to meet IP65 ingress protection requirements.
Key features:
- Class A pressure regulator (EN 88) with integrated solenoid valve (EN 161)
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet connection: DN 15 (1/2") Rp internal thread
- Features rapid actuation mechanism
- Mains voltage: 24 V DC; electrical connection via M20 cable gland
- FM and SA approved; EU certified
- Includes right-side accessories such as a pressure switch (30–110 mbar) with test point, plus two screw plugs on the left side
- No inlet flange included; reduced valve seat design
