Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, IP65

The HONEYWELL KROMSCHRODER VAD1-/20R/NW-50A is a pressure regulator intended for use in applications involving control and monitoring of gas pressure within the specified parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It features an integrated pilot lamp for status indication and features an opening and closing mechanism per product specifications.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland, mains voltage 24 V DC
• Protection rating: IP65
• Certifications: FM, SA approved; EU certified
• Size designation: Size 1; no inlet flange included
• Accessories include right-side mounting options for a pressure switch (30–110 mbar) with test point, left side includes two screw plugs
