Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, IP65
Mfr # KS88032227
Zoro # G515401177
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD1-/15R/NW-100B is a pressure regulator intended for regulation and control of gas pressure within compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar. The device features rapid actuation mechanism, includes a pilot lamp for status indication, and has an IP65 rating for ingress protection.
Key features:
- Integrated Class A pressure regulator to EN 88 standard
- Built-in Class A solenoid valve to EN 161 standard
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet connection: DN 15 (1/2") Rp internal thread
- Outlet pressure range: 35–100 mbar
- Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
- Features rapid actuation mechanism with pilot lamp indicator
- FM and SA approved; EU certified; IP65 rated enclosure
- No inlet flange; size designation: Size 1
