Gas Pressure Regulator with Solenoid Valve, DN 15, 24V DC, IP65 Rated

The HONEYWELL KROMSCHRODER VAD1-/15R/NQ-25B is a pressure regulator intended for regulation and control of gas pressure in industrial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and features an outlet connection of DN 15 (1/2'') Rp internal thread. The device includes a pilot lamp for status indication and is constructed to IP65 standards.

Key features include:

• Integrated Class A pressure regulator to EN 88
• Integrated Class A solenoid valve to EN 161
• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2'') Rp internal thread
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of the connection box
• Outlet pressure range: 35–100 mbar; reduced valve seat design
• Accessories include right-side mountable pressure switch (30–110 mbar) with test point, left-side screw plugs
• Pilot lamp included; FM and SA approved; EU certified; no inlet flange
