Gas Pressure Regulator with Solenoid Valve, DN 15, 35–100 mbar, 24V DC
Mfr # KS88001097
Zoro # G715398680
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD1-/15R/NQ-100B is a pressure regulator intended for regulation and control of gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features an outlet connection of DN 15 (1/2" Rp internal thread) and operates within an outlet pressure range of 35–100 mbar. The device supports a maximum inlet pressure of 500 mbar (7 psig) and is equipped with a pilot lamp for status indication.
Key features:
- Integrated Class A pressure regulator to EN 88 standard
- Built-in Class A solenoid valve to EN 161 standard
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet: DN 15 (1/2") Rp internal thread
- Outlet pressure range: 35–100 mbar
- Features rapid actuation mechanism
- Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side
- IP65 rated enclosure protection
- FM and SA approved; EU certified
- No inlet flange included; size designation: Size 1
