Gas Pressure Regulator with Solenoid Valve, DN 15, 500 mbar, 24V DC
Mfr # KS88003656
Zoro # G915401005
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD115R/NW-100B is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and features an outlet connection size DN 15 (1/2" Rp internal thread). The device is equipped with a pilot lamp for status indication and features rapid actuation mechanism.
Key features include:
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet connection: DN 15 (1/2" Rp internal thread)
- Outlet pressure range: 35–100 mbar
- Electrical specifications: Mains voltage 24 V DC; M20 cable gland electrical connection
- Protection rating: IP65
- Certifications: FM, SA approved; EU certified
- Additional components: Pilot lamp, right-side accessory port for pressure switch (30–110 mbar), left-side screw plugs
- No inlet flange included
