Gas Pressure Regulator with Solenoid Valve, DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD1-/20R/NQ-50A is a pressure regulator intended for use in applications requiring gas pressure regulation within specified parameters. It integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161). The unit features an outlet connection of DN 15 (1/2" Rp internal thread) and operates at a maximum inlet pressure of 500 mbar (7 psig).

Key features include:

• Outlet pressure range: 35–100 mbar
• Features rapid actuation mechanism as per product specifications
• Integrated pilot lamp for status indication
• Electrical connection via M20 cable gland; mains voltage: 24 V DC
• IP65 rated enclosure for ingress protection
• FM and SA approved; EU certified
• No inlet flange; size 1 configuration
• Right-side accessories: pressure switch (30–110 mbar), test point on outlet side
• Left-side accessories: two screw plugs
