Gas Pressure Regulator with Solenoid Valve, DN15, 24V DC, IP65 Rated
Mfr # KS88027438
Zoro # G815403185
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD1-/20R/NY-100A is a pressure regulator intended for use in the regulation and control of gas pressure in industrial and commercial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It features an outlet connection of DN 15 (1/2" Rp internal thread) without an inlet flange, operates at a maximum upstream pressure of 500 mbar (7 psig), and provides an adjustable outlet pressure range from 35 to 100 mbar.
Key features include:
- Integrated pilot lamp for status indication
- IP65 rated enclosure
- FM and SA approvals; EU certified
- Features rapid actuation mechanism
- Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
- Valve seat: reduced type; size designation: Size 1
- Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left-side two screw plugs
