Gas Pressure Switch, 3–500 mbar, DG..C Series, UL/FM

The HONEYWELL KROMSCHRODER SW,PRESS, GAS,DG 110VC1 6WG /B is a gas pressure switch rated for monitoring positive pressures within the specified pressure range in compatible media including gases, biogas, air, and flue gases. This diaphragm-type switch features a micro switch that operates without silicone components and is intended for applications involving gas pressure monitoring in systems such as boilers or similar equipment within the product’s specifications.

Key features include:

• Pressure range: Adjustable from 3 to 500 mbar (1.2 to 144"WC)
• Switching point adjustment via setting dial or factory set
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Electrical connection: 4-pin plug and socket
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max. 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
