Gas Pressure Switch - 3–500 mbar, Diaphragm Type, DG Series

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 110VC8D 6W is a gas pressure switch rated for monitoring positive gas pressures within the specified range in compatible systems. This diaphragm-type switch features a micro switch mechanism and does not contain silicone, ensuring compliance with safety standards. The unit allows for switching point adjustment either via an external setting dial or can be supplied factory set.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Electrical connection via a four-pin plug and socket
• Certified by EU authorities; listed by UL; approved by FM and AGA; RoHS compliant
