Gas Pressure Switch, Adjustable, DG Series, 0.4-500 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 50H 3T is a gas pressure switch rated for monitoring positive gas and air pressures, as well as negative and differential air pressures within specified parameters. This device includes a setting dial to adjust the switching point within the specified range and operates with media such as gas, air, and flue gases. The DG series includes both European (DG) and US (DG..T) versions, each offering specific certifications and connection options.

Key features:

• Adjustable switching point using a setting dial
• Compatible with gas, air, or flue gases in positive pressure applications; compatible with air or flue gases in negative/differential pressure applications
• Available in European version (DG: EU certified, AGA/EAC approved) with range of 0.4 to 500 mbar (0.16 to 200 "WC), internal Rp 1/8" & Rp 1/4" pneumatic connections
• US version (DG..T: UL Listed/FM Approved) offers range of 0.2 to 200" WC with internal NPT connections
• Electrical contacts available in silver or gold variants; multiple electrical connection types including screw terminals and plug/socket options
• Silicon-free construction
