Gas Pressure Switch, DG 110C8D 5S, 3–500 mbar, UL/FM/AGA

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 110C8D 5S is a gas pressure switch rated for use with positive pressure in gases, biogas, air, and flue gases as specified by manufacturer guidelines. This diaphragm-type switch features a micro switch mechanism that is constructed without silicone components. It features adjustable or factory-set switching points within the product’s technical specifications to accommodate various system requirements.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Electrical connection via a four-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved
• Constructed without silicone
