Gas Pressure Switch - DG 40VC8D, 3–500 mbar, Silicone-Free

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 40VC8D 6W is a gas pressure switch rated for monitoring positive pressure in compatible gases within specified ranges. This diaphragm-type switch features a micro switch that operates without silicone components and is intended for detection and control of gas pressures as specified by manufacturer’s guidelines.

Key features include:

• Pressure range: Adjustable from 3 to 500 mbar (1.2 to 144"WC)
• Switching point adjustment: Via setting dial or factory set
• Pneumatic connections: Internal (1x or 2x Rp 1/4), external (Rp 1/8 or Rp 1/4)
• Electrical contacts/switching capacity:
  • CE version: Silver contacts (24–250V AC, 0.05–5A); Gold contacts (5–250V AC, 0.01–5A) - UL versions: Gold contacts (max. 30V AC, 0.05A); Silver contacts (30–240V AC, up to 5A)
  • Electrical connection via a four-pin plug and socket
  • Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
  • Silicone-free construction
