Gas Pressure Switch, DG 45VC5 5W, 3–500 mbar, Diaphragm Type

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 45VC5 5W is a gas pressure switch rated for use with positive pressures in gases, biogas, air, and flue gases. This diaphragm-type switch features a micro switch mechanism constructed without silicone components. It is available with adjustable or factory-set switching points and is compatible with various pneumatic connections.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Electrical connection via a four-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
