Gas Pressure Switch, DG 500BG 6, 0.4–500 mbar Range

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 500BG 6 is a gas pressure switch rated for use with positive gas and air pressures, negative, and differential air pressures within the specified ranges. This device includes a setting dial to adjust the switching point within product specifications and operates with media such as gas, air, and flue gases. The DG model represents the European version of this product.

Key features include:

• Pressure range: 0.4 to 500 mbar (0.16 to 200 "WC)
• Pneumatic connections: Internal Rp 1/8" (2x), Rp 1/4" (2x)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A)
• Electrical connection types: Screw terminals with M16x1.5 cable gland or a four-pin plug/socket
• Certifications: EU certified, AGA approved, EAC approved
• Construction is silicon-free
