Gas Pressure Switch DG 6UG-4, Adjustable, EU/US Certified

The HONEYWELL KROMSCHRODER Gas Pressure Switch DG 6UG-4 is a pressure switch rated for use with positive gas and air pressures, as well as negative and differential air pressures within specified parameters. It includes an adjustable switching point that can be set using the provided dial and operates with media such as gas, air, and flue gases. The unit is silicon-free and available in versions compliant with European (DG) or US (DG..T) standards.

Key features include:

• Adjustable switching point using a setting dial
• Suitable for use with gas, air, or flue gases in positive pressure; compatible with air and flue gases in negative/differential pressure applications
• Available in EU-certified (AGA, EAC approved) or UL Listed/FM Approved versions
• Electrical contacts: silver (24–250V AC, 0.05–5A), gold (5–250V AC, 0.01–5A)
• Pneumatic connections: Internal Rp 1/8" or Rp 1/4"
• Electrical connection options: screw terminals with M16x1.5 cable gland or 4-pin plug/socket
