Gas Pressure Switch, DG Series, 0.4–500 mbar, IP54

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 150U 6,30 150 MBAR,IP54 is a gas pressure switch rated for use with positive, negative, and differential gas and air pressures. This device includes a setting dial to adjust the switching point within specified parameters and operates with media such as gas, air, and flue gases. The DG model represents the European version of this series.

Key features include:

• Pressure range: 0.4 to 500 mbar (0.16 to 200 "WC)
• Pneumatic connections: Internal Rp 1/8" (2x), Rp 1/4" (2x)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A)
• Electrical connection: Screw terminals with M16x1.5 cable gland or optional 4-pin plug/socket
• Housing protection rating: IP54
• Certifications: EU certified, AGA approved, EAC approved
