Gas Pressure Switch, DG Series, 0.4–500 mbar Range

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 500B 6 is a gas pressure switch rated for monitoring positive gas and air pressures, as well as negative and differential air pressures within the specified pressure range. This product falls under the category of pressure switches and is compatible with gases, air, and flue gases within the specified parameters. The DG series is available in European (DG) and US (DG..T) versions.

Key features include:

• Pressure range: 0.4 to 500 mbar (0.16 to 200 "WC)
• Media compatibility: Gas, air, flue gases for positive pressure; air and flue gases for negative/differential pressure
• Pneumatic connections: Internal Rp 1/8" (2x), Rp 1/4" (2x)
• Contact options: Silver contacts (24–250V AC, 0.05–5A); Gold contacts (5–250V AC, 0.01–5A)
• Electrical connection types: Screw terminals with M16x1.5 cable gland or a four-pin plug/socket
• Certifications listed include EU certification, AGA approval, EAC approval
