Gas Solenoid Valve – 1–9 Size, Thread/Flange, IP65, SIL 3
Mfr # KS88015879
Zoro # G615418808
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS1-/NW is a solenoid valve intended for use in applications requiring the control of gas and air flow via automatic shut-off mechanisms. It is configured to be closed in a de-energized state per manufacturer specifications and rated for operation at pressures up to 500 mbar as specified by the manufacturer. The unit has an IP65 enclosure rating; includes pilot lamp, adjustable flow mechanism, and multiple connection types (threaded or flanged) as described in technical documentation. It is certified under relevant EU directives; FM and CSA approved; compatible with systems rated up to SIL 3 and PL e according to applicable standards.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: thread or flange
- Operation modes: available with quick opening/closing or slow opening/quick closing actuation modes per product specification
- Mains voltage compatibility: compatible with mains voltages of either 24 V DC, 120 V AC, or 230 V AC within specified tolerances
- Electrical connection via terminal block
- Available configurations include models equipped with position indicators/visual indicators; optional bypass/pilot gas valves; optional pressure switches DG../VC
