Gas Solenoid Valve – 500 mbar, IP65, Class A, DN10–125

The HONEYWELL KROMSCHRODER VAS1T-/NQ is a Class A solenoid valve intended for use in systems requiring automatic shut-off of gas and air. This valve is configured to be closed in the de-energized state and is rated for operation at a maximum pressure of 500 mbar. It features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. The unit holds EU certification as well as FM and CSA approvals, with may be used in applications with requirements up to SIL 3 and PL e, subject to system design.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
