Gas Solenoid Valve - 500 mbar, IP65, Class A, FM/CSA Approved

The HONEYWELL KROMSCHRODER VAS350/-F/NW is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve is configured to be closed in a de-energized state and is rated for operation up to a maximum pressure of 500 mbar. It includes pilot lamp, adjustable flow mechanism, and has an IP65 ingress protection rating. The unit is certified according to EU standards; FM and CSA approved; compliant with requirements applicable to systems classified up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available in configurations including position indicator, visual indicator, integrated bypass/pilot gas valve option(s), or integrated pressure switches DG../VC
