Gas Solenoid Valve – 500 mbar, IP65, Class A, Pilot Lamp

The HONEYWELL KROMSCHRODER VAS240/-R/NY is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve is configured to be closed when not energized and is rated for operation at pressures up to 500 mbar. It includes a pilot lamp, adjustable flow settings, and an enclosure with an IP65 rating. The unit holds EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation: quick opening/closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
