Gas Solenoid Valve - 500 mbar, IP65, Class A, SIL 3

The HONEYWELL KROMSCHRODER VAS 665F05LW3B/PP/PP is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This valve remains closed when not energized. It features a rated maximum operating pressure of 500 mbar and is equipped with pilot lamp and adjustable flow settings. The unit is rated to IP65 for ingress protection, carries EU certification, FM and CSA approvals, and holds certification meeting requirements up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Available with quick opening/closing or slow opening/quick closing operation modes
• Suitable for connection to mains voltages of 24 V DC, 120 V AC, or 230 V AC within specified limits
• Electrical connection via terminal block
• Available versions include models featuring position indicators, visual indicators, bypass valves, pilot gas valves, or integrated pressure switches DG../VC
