Gas Solenoid Valve - 500 mbar, IP65, Class A, VAS Series

The HONEYWELL KROMSCHRODER VAS665F05LW3B/MM/PP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in accordance with EN 161 standards, remains closed when not energized, and supports a maximum operating pressure of 500 mbar. This model includes pilot lamp and adjustable flow features, is rated IP65 for ingress protection, and holds EU certification as well as FM and CSA approvals. The valve is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick opening/closing or slow opening/quick closing operation
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Models available with optional position indicator, visual indicator, integrated bypass/pilot gas valve, or integrated pressure switches DG../VC
