Gas Solenoid Valve - 500 mbar, IP65, Class A, VCS Series

The HONEYWELL KROMSCHRODER VCS665F05NLWLE/PPB-/3-PP is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. It operates in a normally closed position when de-energized and supports a maximum operating pressure of 500 mbar. This valve includes a pilot lamp, flow adjustment capability, and an enclosure rated to IP65. It holds EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
